Ice maker water cooling ice cube 14 g 22 kg / 24 h | REDFOX - SS 25 W


Ice maker water cooling ice cube 14 g 22 kg / 24 h | REDFOX - SS 25 W

                    Product no: 00007371

                        B-grade
                        Bestseller
                        Campaign
                        Clearance sale
                        New release
                        Not for sale

                        Cooling type: Water
Max ambient temperature [°C]: 43
Min ambient temperature [°C]: 5
Type of ice: Cube
Weight of ice [g]: 14.00
Production per day [kg]: 21
Water consumption [ l/h ]: 23.50
Container for ice: Yes
Ice storage capacity [kg]: 6
Material: Stainless steel

                                1,777.00 EUR

                    share Sdílet produkt

Technical details

Documentation

Photos/Videos

Accessories

Technical details

SAP Code	00007371
Net Width [mm]	350
Net Depth [mm]	475
Net Height [mm]	595
Net Weight [kg]	32.00
Gross Width [mm]	430
Gross depth [mm]	540
Gross Height [mm]	720
Gross Weight [kg]	36.00
Device type	Electric unit
Power electric [kW]	0.260
Loading	230 V / 1N - 50 Hz
Refrigerant	R290
Cooling type	Water
Material	Stainless steel
Min ambient temperature [°C]	5
Max ambient temperature [°C]	43
Production per day [kg]	21
Water consumption [ l/h ]	23.50
Type of ice	Cube
Weight of ice [g]	14.00
Container for ice	Yes
Ice storage capacity [kg]	6
Max supply water temperature [°C]	38
Min supply water temperature [°C]	5
Drain pump	No
Cross-section of conductors CU [mm²]	0,5
Water supply connection	3/4"
Diameter nominal	DN 50

                                Declaration of conformity
download

                                Instruction manual
download

                                DWG
download

                                Technical data sheet
download

                                Drawing
download
