Ice maker air cooling ice cube 22 g 54 kg / 24 h | REDFOX - SS 60 A


Ice maker air cooling ice cube 22 g 54 kg / 24 h | REDFOX - SS 60 A

                    Product no: 00007376

                        B-grade
                        Bestseller
                        Campaign
                        Clearance sale
                        New release
                        Not for sale

                        Cooling type: Air
Max ambient temperature [°C]: 43
Min ambient temperature [°C]: 5
Type of ice: Cube
Weight of ice [g]: 22.00
Production per day [kg]: 54
Water consumption [ l/h ]: 4.70
Container for ice: Yes
Ice storage capacity [kg]: 30
Material: Stainless steel

                                2,928.00 EUR

                    share Sdílet produkt

Technical details

Documentation

Photos/Videos

Accessories

Technical details

SAP Code	00007376
Net Width [mm]	515
Net Depth [mm]	645
Net Height [mm]	836
Net Weight [kg]	54.00
Gross Width [mm]	585
Gross depth [mm]	700
Gross Height [mm]	965
Gross Weight [kg]	67.10
Device type	Electric unit
Power electric [kW]	0.510
Loading	230 V / 1N - 50 Hz
Refrigerant	R290
Cooling type	Air
Material	Stainless steel
Min ambient temperature [°C]	5
Max ambient temperature [°C]	43
Production per day [kg]	54
Water consumption [ l/h ]	4.70
Type of ice	Cube
Weight of ice [g]	22.00
Container for ice	Yes
Ice storage capacity [kg]	30
Max supply water temperature [°C]	35
Min supply water temperature [°C]	5
Drain pump	No
Cross-section of conductors CU [mm²]	0,5
Water supply connection	3/4"
Diameter nominal	DN 50

                                Declaration of conformity
download

                                Instruction manual
download

                                DWG
download

                                Technical data sheet
download

                                Drawing
download
